UNDERGROUND PIPE DRILLING HORIZONTAL DIRECTIONAL DRILLING MACHINE: HD 120A
+
  • UNDERGROUND PIPE DRILLING HORIZONTAL DIRECTIONAL DRILLING MACHINE: HD 120A

UNDERGROUND PIPE DRILLING HORIZONTAL DIRECTIONAL DRILLING MACHINE: HD 120A

ATI VIET TRUNG COMPANY LIMITED



产品描述

IMAGES AND VIDEO INTRODUCTION

MAIN TECHNICAL FEATURES AND FEATURES

– Fully hydraulic drive: variable speed power head

– Travel mode: Self-propelled with integrated rubber tracks, causing negligible impact to the road

– Power source drive method: hydraulic motor, gear reduction box

– Loading and pulling method: hydraulic motor, cylinder, chain

– Stirring motor 480 (water-based diesel engine, 4 cylinders)

– High pressure cast iron hydraulic pump

– Cycloid engine

MAIN SPECIFICATIONS

  MODEL NUMBER
Drill Platform HD120A 1
Drill Pipe combined with high volume

Φ50x1500mm

34
Directional Drill Bit   1
Leaning Directional Palm Drill Bit   1
Drill Bit Φ150 Φ250 2
Heading Connection Cut Φ60 1
Protective Section Connection Cut Φ60 1
Anti-slipping Cube Φ60 8
Pad   1
Ground Anchor Φ60 3
Dividing Unit 8 1

TECHNICAL SPECIFICATIONS
Pullback Force  T 12
Charging Force T 12
Spinning Torque N.m 2400
Spinning Speed rpm 140
Impulse Interval mm 1700
Moving Speed  km/h 3-8km/h
Hydraulic System Pressure Mpa 15
Drill Pipe's Technical Specifications mm Φ50x1500 Overall
Drill Ankle degree 8-20
Engine Model    480
Server Weight  km 1500
Device Size  mm 2900x1300x1600


If you need advice on machines, please leave your phone number or contact the hotline for the best service!

ATI VIET TRUNG COMPANY LIMITED
HOTLINE: MR Quang: 0979573000
